MIMAKI CFL-605RT - Setting the Command Origin

1-22
Matching the PC Specifications
Setting the Command Origin
This setting aligns the unit command origin position with the command origin position in the CAD system used.
For more information on the command origin position handled by the CAD system, see the CAD Instruction
Manual.
1
Select [PLOT SETTING] of the set up menu.
(1) Press the key in LOCAL.
(2) Press to select [SET UP] and press the key.
(3) Press to select [PLOT SETTING].
(4) Press the key.
2
Press the jog key or to select [ORIGIN],
and ress the key.
3
Press the jog key or to select Setting.
• Set values: LOW-LEFT , CENTER
4
Press the key.
• Press if you do not want to save the setting.
5
Press the key twice for terminating this function.
Item Set value
LOW-LEFT
Lower-left of the maximum effective cutting area.
CENTER
Center of the maximum effective cutting area.
FUNCTION
<PLOT SETT I NG>
OR I G I N : LOE - L E F T
<PLOT SETT I NG>
ROTA T I ON : CENT ER
