MIMAKI CFL-605RT - Set the Configurations with a Computer

3-32
Set the configurations with a computer
Set the configurations with a computer
Set the communication condition with the RS-232C interface.
1
Select [INTERFACE] of the set up menu.
(1) Press the key in LOCAL.
(2) Press to select [SET UP] and press the key.
(3) Press to select [INTERFACE].
(4) Press the key.
2
Press the jog key or to select [RS-232C] .
3
Press the key.
4
Press the jog key or to select [BAUD
RATE].
• Set values: 1200, 2400, 4800, 9600, 19200, 38400(bps)
5
Press the key.
6
Press the jog key or to select the following items.
• The following items are provided for the setting of registration mark detection:
Data bits, Parity / Stop bits / Handshake
• See pages P.3-33 for the contents of each setting item.
7
Press the key.
8
Press the jog key or to select the set values.
• See pages P.3-33 for the contents of each setting item.
• The recommended setting value is “38400(bps)”.
• Set the transfer speed of the host computer to CFL-605.
FUNCTION
<INTERFACE>


RS - 2 3 2C [ ENT ]
<RS SETT I NG>


BAUD RATE : 9600
<RS SETT I NG>
BAUD RATE : 38400
