3-31
1
1
3
Useful Function
5
6
Other Useful Functions
Resolution (GDP
*1
) Setting
This setting aligns the resolution of the unit with the resolution of the CAD system used.
For more information on the resolution of the CAD system, see the CAD Instruction Manual.
1
Select [COMMAND SETTING] of the set up menu.
(1) Press the key in LOCAL.
(2) Press to select [SET UP] and press the key.
(3) Press to select [COMMAND SETTING].
(4) Press the key.
2
Press the jog key or to select [GDP UNIT].
3
Press the key.
4
Press the jog key or to select Setting.
• Set values:0.025mm, 0.010mm
5
Press the key.
• Press if you do not want to save the setting.
6
Press the key several times to end the setting.
*1.GDP:Graphic Display Pitch
FUNCTION
<COMMAND SETT I NG>


GDP UNI T : 0 . 025mm
<COMMAND SETT I NG>
GDP UNI T : 0 . 025mm
<COMMAND SETT I NG>
GDP UNI T : 0 . 010mm
