3-30
Setting the Effective Area Return Values (OH UNIT)
Sets which value to return to the CAD system when the unit receives the effective area coordinate output
command from the CAD system.
INITIAL: Return the maximum value of the effective cutting area of the machine.
SET VAL: Returns the value that was set in the configuration of the cut area.
1
Select [COMMAND SETTING] of the set up menu.
(1) Press the key in LOCAL.
(2) Press to select [SET UP] and press the key.
(3) Press to select [COMMAND SETTING].
(4) Press the key.
2
Press the jog key or to select [OH UNIT].
3
Press the key.
4
Press the jog key or to select Setting.
• Set values: INITVAL, SETVAL
5
Press the key.
• Press if you do not want to save the setting.
6
Press the key several times to end the setting.
FUNCTION
<COMMAND SETT I NG>


OH ; UN I T : I N I TVA L
<COMMAND SETT I NG>
OH ; UN I T : I N I TVA L
<COMMAND SETT I NG>
OH ; UN I T : SE T VA L
