3-24
Setting of the offset value of the cutting edge correction pressure
Set when there is an uncut at the start point and end point of the cut.
1
Select [PLOT SETTING] of the set up menu.
(1) Press the key in LOCAL.
(2) Press to select [SET UP] and press the key.
(3) Press to select [PLOT SETTING].
(4) Press the key.
2
Press the jog key or to select [ADJ-PRS
OFFSET], and ress the key.
3
Press the jog key or to select Setting.
• Set values: -9 ~ +9 (Around -30g to around 30g)
4
Press the key.
• Press if you do not want to save the setting.
5
Press the key twice for terminating this function.
<PLOT SETT I NG>
ADJ - PRS OFFSET : 0
<PLOT SETT I NG>
ADJ - PRS OFFSET : 3
