MIMAKI CFL-605RT - Selecting Tools and Conditions

2-10
Selecting Tools
Select the tool condition
Before cutting (plotting), select the tool condition depending on the sheet and the tool type to be used.
1
Press the key in LOCAL mode.
2
Press key and select Unit.
• Set values: A, B
3
Press key.
4
Press key and select TOOL.
• The selectable tools differ according to the type of unit.
5
Press key.
• The setting is saved.
• Press if you do not want to save the setting.
6
Press key to display the cut conition to set, and press the key.
• The displayed items differ according to the tool. ( Set Items )
7
Press key to set the setting value, and press the key.
• The setting is saved.
• Press if you do not want to save the setting.
8
To select and set another item, repeat Steps 7 and 8.
• For details about the settings, see “Set Items”.
9
When all settings are complete, press key.
Unit
Tool A B
Pen Applicable N/A
Swivel blade Applicable N/A
Rec. Cutter 1 to 3 N/A Applicable
 Cutter
N/A Applicable
Roller 1 to 3 N/A Applicable
<TOOL SELECT>
A:PEN
<TOOL SELECT>
B:REC.CUTTER1
<TOOL SELECT>
B:REC.CUTTER1
