2-16
Adjusting the Blade to Match the Workpiece
Adjusting the Swivel Blade
After adjusting the blade edge, set the cut condition and perform test cut to check whether cutting is performed
well.
1
Turn the adjusting knob to adjust the protruding
amount of the cutter.
• The blade protrudes when turn the adjustment knob clockwise.
( 0.5 mm per revolution)
To Next Page
