MIMAKI CFL-605RT - Height Setting at the Pen Tool Lifted

3-23
1
1
3
Useful Function
5
6
Other Useful Functions
Height setting at the pen tool lifted
Set the height when lifting the tool.
1
Select [PLOT SETTING] of the set up menu.
(1) Press the key in LOCAL.
(2) Press to select [SET UP] and press the key.
(3) Press to select [PLOT SETTING].
(4) Press the key.
2
Press the jog key or to select [UP HIGHT],
and press the key.
3
Press the jog key or to select Setting.
• For thick media or when the cutter scratches the media because
the sheet is not flat, set the amount of lifting bigger.
• Set values:
50%, 75%, 100%
4
Press the key.
• Press if you do not want to save the setting.
5
Press the key twice for terminating this function.
FUNCTION
<PLOT SETT I NG>
PEN UP H I GHT : 50%
<PLOT SETT I NG>
PEN UP H I GHT : 75%
