Troubleshooting
6
Adjusting the Tools
Circle  Correction
Conduct the operations below to correct for displacements if the start and end points do not match when cutting
(drawing) a circle.
Setting Arc  Correction
Before setting circle  correction, set arc  correction to Enable.
1
Press the key in the local mode.
2
Press the jog key or to select [TOOL
ADJUST] .
3
Press the key.
4
Press the jog key to select tool.
• Set value: REC.CUTTER1~2, CUTTER, ROLLER1~3
5
Press the key.
6
Attach the selected tool ( P.2-22).
7
Press the jog key to select [CIRCLE
ADJUST].
8
Press the key.
9
Press the jog key to select [ CORRECT].
10
Press the key.
11
Press the jog key to select “ON”.
12
Press .
• The setting is saved.
• Press if you do not want to save the settings.
<FUNCT ION>


SET UP [ ENT ]
FUNCTION
<FUNCT ION>


TOOL ADJUST [ ENT ]
<TOOL SELTECT>
TOOL : B : REC . CUTTER1
<TOOL SELTECT>
TOOL : B : REC . CUTTER1
<REC . CUTTER1 ADJUST>
CIRCLE ADJUST [ ENT ]
<C I RCLE ADJUST>


R<5 : 0 . 0 º
<C I RCLE ADJUST>


 CORRECT : OF F
<C I RCLE ADJUST>
 CORRECT : ON
<C I RCLE ADJUST>


R<5 : 0 . 0 º
