Assigning Pen Numbers
9
Press the key.
10
Press the jog key or and select the pen
number to be set
• Here select the pen number "2".
• Set values: 1 to 6
11
Press the key.
12
Press the jog key or to select unit.
• Here choose the unit "B".
• Set values: A, B
13
Press the key.
14
Press the jog key or to select tool.
• The set values differ according to the mounted tools.
• Here choose the tool "REC.CUTTER1".
• Unit A: PEN, SWIVEL
• Unit B: REC.CUTTER1 to 2, CUTTER, ROLLER1 to 3
15
Press the key.
• If set the other pen number, repeat the operation from step 5 to 10.
16
Press the key twice for terminating this
function.
• The initial value of each pen number is as follows.
<PEN No . SELECT>
No . 1 A : PEN
<PEN No . SELECT>
No . 2 B : ROLLER1
<PEN ASS I GN>
No . 2 B : ROLLER1
<PEN ASS I GN>
No . 2 B : REC . CUTTER1
<PLOT SETT I NG>
PEN ASS I GN [ ENT ]
Tool number Unit / Tool
1 B / REC.CUTTER1
2 B / ROLLER1
3B / CUTTER
4 B / ROLLER2
5 A / SWIVEL
6 A / PEN
To Next Page
