Set Item
Tool Type
Set value Set value
AB
Swivel cutter
Pen
Reciprocating cutter
Crease roller
Cutter
W ROLLER
○
OFF, 0.1 ~ 1.0mm
Centering the original data, drawing two ruled lines
offsetting the setting value.
R5 SPEED
○
OFF, 1~2 (cm/s)
Speed for cutting an arc with a radius less than 5 mm.
If OFF, the previously set speed is used for cutting.
○
○
OFF,
0.5 (
mm
/s) ~ 2.0 (cm/s)
R10 SPEED
○
OFF, 1~5 (cm/s)
Speed for cutting an arc of the radius between 5mm but
less than 10mm.
If OFF, the previously set speed is used for cutting.
○
○
OFF,
0.5 (
mm
/s) ~ 2.0 (cm/s)
R15 SPEED
○
OFF, 1~10 (cm/s)
Speed for cutting an arc of the radius between 10mm
but less than 15mm.
If OFF, the previously set speed is used for cutting.
○
○
OFF,
0.5 (
mm
/s) ~ 2.0 (cm/s)
R20 SPEED
○
OFF, 1~15 (cm/s)
Speed for drawing an arc with a radius at least 15 mm
but less than 20 mm.
If OFF, the previously set speed is used for drawing.
R30 SPEED
○
OFF, 1~20 (cm/s)
Speed for drawing an arc with a radius at least 20 mm
but less than 30 mm.
If OFF, the previously set speed is used for drawing.
R40 SPEED
○
OFF, 1~25 (cm/s)
Speed for drawing an arc with a radius at least 30 mm
but less than 40 mm.
If OFF, the previously set speed is used for drawing.
R50 SPEED
○
OFF, 1~30 (cm/s)
Speed for drawing an arc with a radius at least 40 mm
but less than 50 mm.
If OFF, the previously set speed is used for drawing.
R100 SPEED
○
OFF, 1~30 (cm/s)
Speed for drawing an arc with a radius at least 50 mm
but less than 100 mm.
If OFF, the previously set speed is used for drawing.
• When "SORTING" is enabled, the machine cannot recognize any arc. Therefore, the "R**SPEED"
settings that specify the speed for cutting an arc are not reflected.
Consequently, to select any "R** SPEED" setting, you must disable the”SORTING” setting ( P.3-
14).
