171
6
Graphical display
6.1.Graphical display description
(5) Weighing status display
A corresponding lamp illuminates according to the weighing status.
(6) [Y0] key
Sets a lower limit value of a weighing value for the graphical display. A currently set
lower limit value is displayed in yellow under the key.
(7) [CURSOR ON] key
Enables cursor display.
POINT
- A cursor can be displayed after completion of weighing.
- For more information about the display when [CURSOR ON] is selected, refer to
³&KHFNLQJDZHLJKLQJYDOXHRYHUDVSHFL¿HGGXUDWLRQ&8562521´
(8) [GROSS/NET] key
Switches between gross and net weight displays. Pressing [GROSS] switches to gross
weight display. Pressing [NET] switches to net weight display.
(9) [T] key
Sets a weighing time during which the graph is displayed. A currently set weighing time
is displayed in yellow under the key.
(10) [START/STOP] key
Starts/stops weighing operation.
POINT
- When a cursor is displayed, the [START/STOP] key is not displayed.
