9.7.RS-422/485 interface
256
External equipment
9
9.7.3. Communication setting
7KHIROORZLQJLWHPVPXVWEHVHWDFFRUGLQJWRWKHVSHFL¿FDWLRQVRIWKH56LQWHUIDFH
Setting item Description Selection (initial value)
Baud rate Sets the baud rate of the RS-
422/485 interface.
1 200 bps, 2 400 bps, 4 800 bps, 9
600 bps, 19 200 bps, 38 400 bps
(LQLWLDOYDOXHESV)
Data bit length Sets the data bit length of the
RS-422/485 interface.
7 bit, 8 bit (LQLWLDOYDOXHELW)
Parity Sets the parity bit of the RS-
422/485 interface.
121(2''(9(1LQLWLDOYDOXH
ODD)
Stop bits Sets the stop bit of the RS-
422/485 interface.
1 bit, 2 bit (LQLWLDOYDOXHELW)
Terminator Sets the terminator of the RS-
422/485 interface.
CR, CR+LF (LQLWLDOYDOXH&5/))
Add the decimal
point
Sets whether or not a decimal
point is added to output data.
121((;,67,1*LQLWLDOYDOXH
NONE)
Address Sets an address number for
communication.
0 to 31 (,QLWLDOYDOXH)
RS-422/RS-485 Switches the communication
method between RS-422 and
RS-485.
RS-422, RS-485 (LQLWLDOYDOXH56
422)
Data delay time Sets a data delay time while
communicating with RS-485.
Data return from CSD-912B is
delayed when the sending
terminal on the host side, such as
a PC or a sequencer, is of low
impedance upon completion of
the host-side transmission.
0.00 to 9.99 (,QLWLDOYDOXH)
Operation mode Sets an operation mode of the
RS-422/485 interface.
COMMAND MODE, STREAM
MODE (LQLWLDOYDOXH&200$1'
MODE)
Target of stream Sets data to be output when the
operation mode is in stream
mode.
LOAD DISPLAY, GROSS, NET,
/2$'',63:,7+67$7(initial
YDOXH/2$'',63/$<)
