9.5.BCD output
238
External equipment
9
9.5.3. BCD output connector pin arrangement
The pin arrangement of the BCD output connector varies depending on the output target
setting.
POINT
- For more information about output target setting, refer to "9.5.6. (1) Output target
setting".
Ŷ:KHQ>/2$'',63/$<@>*5266@>1(7@RU>7$5(@LVVHWDVWKHRXWSXWWDUJHW
Pin
Output
description
Pin
Output
description
A1 1 x 10
0
B1 2 x 10
0
A2 4 x 10
0
B2 8 x 10
0
A3 1 x 10
1
B3 2 x 10
1
A4 4 x 10
1
B4 8 x 10
1
A5 1 x 10
2
B5 2 x 10
2
A6 4 x 10
2
B6 8 x 10
2
A7 1 x 10
3
B7 2 x 10
3
A8 4 x 10
3
B8 8 x 10
3
A9 1 x 10
4
B9 2 x 10
4
A10 4 x 10
4
B10 8 x 10
4
A11 1 x 10
5
B11 2 x 10
5
A12 4 x 10
5
B12 8 x 10
5
A13 ERROR B13 N.C.
A14 STABLE B14 GROSS
A15 Decimal point 10
1
B15 Decimal point 10
2
A16 Decimal point 10
3
B16 Decimal point 10
4
A17 29(5 B17 POL.
A18 P. C. B18 HOLD
A19 COM. 3 B19 COM. 3
A20 BCD-ENABLE B20 F.G.
