9.5.BCD output
239
External equipment
9
Ŷ:KHQ>$&&809$/8(@RU>7,0(6@LVVHWDVWKHRXWSXWWDUJHW
Pin
Output
description
Pin
Output
description
A1 1 x 10
0
B1 2 x 10
0
A2 4 x 10
0
B2 8 x 10
0
A3 1 x 10
1
B3 2 x 10
1
A4 4 x 10
1
B4 8 x 10
1
A5 1 x 10
2
B5 2 x 10
2
A6 4 x 10
2
B6 8 x 10
2
A7 1 x 10
3
B7 2 x 10
3
A8 4 x 10
3
B8 8 x 10
3
A9 1 x 10
4
B9 2 x 10
4
A10 4 x 10
4
B10 8 x 10
4
A11 1 x 10
5
B11 2 x 10
5
A12 4 x 10
5
B12 8 x 10
5
A13 1 x 10
6
B13 2 x 10
6
A14 4 x 10
6
B14 8 x 10
6
A15 1 x 10
7
B15 2 x 10
7
A16 4 x 10
7
B16 8 x 10
7
A17 29(5 B17 POL.
A18 P. C. B18 HOLD
A19 COM. 3 B19 COM. 3
A20 BCD-ENABLE B20 F.G.
POINT
- Output is executed only during weighing operation.
- Do not wire N.C. pins.
- The optional parts mounting section is insulated from the internal circuit by a
photocoupler.
