Data management
8
8.1.Data types
8.1. Data types
A part of setting data and calibration data of CSD-912B is recorded in RAM or EEPROM and
retained even if the power of CSD-912B is turned OFF.
- RAM
This is a memory that is able to rapidly read and write data. It is backed up by a battery.
- EEPROM
This is a nonvolatile memory.
POINT
- The battery life is approximately 10 years in an operating environment at a room
temperature of 20C°. If the screen displays
, this indicates that the battery
needs replacement. In this case, contact us.
- The EEPROM allows approximately 1 000 000 times of data writing.
The content and the storage location of each data type are as follows:
Data type Setting included in the data Stored in Remarks
Zero set data OPERATION OF ZERO, RANGE
OF ZERO
RAM —
Zero tracking data TARGET OF ZERO TRACKING,
ZERO TRACKING TIME, ZERO
TRACKING BAND
RAM —
Tare weight
cancellation data
OPERATION OF TARE, RANGE
OF TARE
RAM —
Brand setting data NAME, HOPPER No. , FINAL,
FREE FALL, PRELIMINARY1,
PRELIMINARY2, OVER, UNDER,
ZERO BAND, FULL, A. F. F.
COMPENSATION,
SUPPLEMENTARY FLOW TIME,
JUDGE. AFTER S-FLOW WAIT,
ACCUM. VALUE, ACCUM.
TIMES, PRESET TARE, INITIAL
FULL FLOW, INITIAL MEDIUM
FLOW
RAM The storage location
can be changed to the
LQWHUQDOÀDVK520
(except accumulation
value data and
accumulation times
data).
Recipe setting
data
NAME, MEAS. 1, MEAS. 2,
MEAS. 3, MEAS. 4, MEAS. 5,
MEAS. 6, MEAS. 7, MEAS. 8,
MEAS. 9, MEAS. 10, ACCUM.
VALUE, ACCUM. TIMES
RAM The storage location
can be changed to the
LQWHUQDOÀDVK520
(except accumulation
value data and
accumulation times
data).
