9.3.External control I/O
220
External equipment
9
Function name Description
RECIPE START Inputs the recipe start signal.
DISCHARGE START Inputs the discharge start signal.
0,;,1*67$57 Inputs the mixing start signal.
M. F. F.
COMPENSATION
Executes manual free fall compensation.
ACCUM. COMMAND Inputs the accumulation signal.
FOMER ACM. DATA
CLR.
Cancels previous accumulated data.
BATCH/DISCHARGE Switches the control mode between batch and discharge modes
ĺ&RQWUROPRGHVHWWLQJ
CODE NO. 1, CODE
NO. 2, CODE NO. 4,
CODE NO. 8, CODE
NO. 10, CODE NO. 20,
CODE NO. 40, CODE
NO. 80
Switches between brand/recipe codes to be weighed by the BCD
input.
PAUSE Temporarily stops weighing operation.
RESTART Restarts a weighing operation that has been temporarily stopped.
CLR ACM. OF BRAND Clears the accumulation value and the accumulation times of a
currently selected brand.
CLR ACM. OF ALL
BRAND
Clears the accumulation value and the accumulation times of all
brands.
CLR ACM. OF RECIPE Clears the accumulation value and the accumulation times of a
currently selected recipe.
CLR ACM. OF ALL
RECIPE
Clears the accumulation value and the accumulation times of all
recipes.
SAFETY INPUT1,
SAFETY INPUT2,
SAFETY INPUT3,
SAFETY INPUT4,
SAFETY INPUT5,
SAFETY INPUT6,
SAFETY INPUT7,
SAFETY INPUT8
,QSXWVWKHVDIHW\FRQ¿UPDWLRQVLJQDOĺ8VLQJVDIHW\FKHFN
input").
FORCED BATCH
FINISH
Forcibly completes weighing operation.
FORCED RECIPE
FINISH
Forcibly completes recipe operation.
FORCED DISCH.
FINISH
Forcibly completes discharge operation.
0$18$/)8//)/2: 2XWSXWVWKHIXOOÀRZVLJQDOGXULQJDVHWOHQJWKRIWLPH
MANUAL MEDIUM
)/2:
2XWSXWVWKHPHGLXPÀRZVLJQDOGXULQJDVHWOHQJWKRIWLPH
MANUAL DRIBBLE
)/2:
2XWSXWVWKHGULEEOHÀRZVLJQDOGXULQJDVHWOHQJWKRIWLPH
MANUAL DISCHARGE Outputs the discharge signal during a set length of time.
0$18$/0,;,1* Outputs the mixing signal during a set length of time.
ERROR RESET Releases an error.
