4.1.About calibration
26
Calibration
4
4.1. About calibration
To make sure that electric signals from the weighing device (load cell) are accurately
displayed on CSD-912B, calibration is the process of matching the value of the weight of the
load on the load cell with the display value of CSD-912B.
Without calibration, CSD-912B cannot display accurate load values. Be sure to calibrate the
LQVWUXPHQWDIWHUFRQ¿JXULQJWKHZHLJKLQJV\VWHP
ex. )When you place a weight of 100 kg on the load cell,
Without calibration
With calibration
POINT
- If operation environment has changed after calibration, recalibrate CSD-912B.
100kg100kg
100kg100kg
12.345 t
100.00 kg
The load value, unit,
position of decimal point,
and etc. are not
accurately displayed.
The accurate load value
is displayed. The unit and
position of decimal point
are properly displayed as
VSHFL¿HGWRR
