USER MANUAL
MINISENTRY-2
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra)S.A.S., BP249, ZI de Vauzelles, 37602
Loches Cedex
131 / 170
Qty
Description
Order No.
1
Interface board kit
108199
1
Mother board kit
108337
1 Protection glass kit
101826
101827
1 Ready to measure light kit
107878
107987
1
Loud speaker kit
108339
1
Rear cover kit
108340
Other parts
As
needed
KITTED HARDWARE. ONE SET INCLUDES:
- 4x 107776 SCREW 4.5 X 80
- 8x 108187 SCREW 3 X 30
- 12x 13402 FLAT WASHER
- 12x107722 WING NUT
108486
As
needed
Standard MiniSentry Base Plate 107759
As
needed
Vehicle Option Base Plate (if applicable) 108314
As
needed
Pipe Caps kit (also used as protective end caps for Standard MiniSentry),
PIPE CAP FOR VEHICLE OPTION, 2 PCS PER SET
107754
1
High voltage “T” adapter
107749
As
needed
Sub-D 15 connector for sensor cables 108123
As
needed
AC Power Cable
EU: 79025
US: 68025
UK: 88559
1
MINISENTRY SENSOR CABLE REPLACEMENT KIT :
- 1x108143 receiver assembly
- 1x108142 emitter assembly
- 1x108144 emitter extend cable
- 1x108145 emitter top extend cable
108487
1 High voltage top member cable 107741
1
1 x 107740 High voltage cable monitor to detector
1 x 107745 High voltage connector to monitor
108490
