Mitsubishi 700 Series

EMBEDDED WEB SERVER
95
6
Server
Device
Content is loaded onto
server device’s file
system for web server
2
Active web content
is delivered to client
XML socket (port 843)
<xreq>
<reMd_dMtM>
<ref>Pr_2<C ref>
<CreMd_dMtM>
<Cxreq>
User accesses
server’s web
page via web
browser (client)
3
http://192.168.16. 111
Active content
executes and
establishes
XML socket
5
http://192.168.16. 111
XML socket (port 843)
<xresp>
<reMd_dMtM>
<ref>Pr_2<C ref>
<vMl>123<CvMl>
:
<Cxresp>
8
http://192.168.16. 111
Programmer authors
active web page
content (via Adobe
Flash, etc.)
File System
HTTP (port 80)
Network or
Internet
1
Client initiates XTPro
requests
6
4
Server responds to
client’s requests
7
XTPro Server
Figure 24: Web Browser-Based Implementation
