PROTOCOL-SPECIFIC INFORMATION
• This product has been self-tested and found to comply with ODVA EtherNet/IP Conformance Test
Software Version CT-13.
• The interface card’s product type code is 2 (AC Drive).
• The EDS file can be obtained from the included CD-ROM or downloaded from the
product web
page on the internet.
• Supports DLR (Device Level Ring) node.
• Supports unconnected messages (UCMM), and up to 16 simultaneous class 1 (I/O) or class 3
(explicit) connections.
• Class 1 implicit I/O supports both multicast and point-to-point (unicast) when producing data in the
T→O direction.
• Point-to-point class 1 connected messages will be produced targeting the IP address of the device
that instantiated the connection, UDP port 0x08AE (UDP port 2222).
• If a class 1 point-to-point connection is established in the (T→O) direction, no more class 1
connections can be established.
• If a class 1 connection’s consuming half (O→T) times out, then the producing half (T→O) will also
time-out and will stop producing.
• If a class 1 or class 3 connection timeout (communication loss) occurs, the driver can be configured
to perform a timeout action. For class 1 connections, the timeout value is dictated by the
scanner/client and is at least four times the RPI (Requested Packet Interval). For class 3
connections, the timeout value is also dictated by the scanner/client, but is typically a much larger
value than for class 1 connections.
