PROTOCOL-SPECIFIC INFORMATION
161
9
simultaneously being commanded in the background via I/O messaging. Indeterminate behavior can
occur if MSG instructions and background I/O data transfers are both writing to the same registers. In
other words, if the I/O messaging example procedure detailed in section 9.2.12 has already been
implemented, and the same program is now being modified to implement explicit messaging, then it is
recommended to inhibit the target module by selecting the “Inhibit Module” checkbox in the Connection
tab of the Module Properties dialog.

Mitsubishi 700 Series Specifications

General

Control Method	Vector Control
Overload Capacity	150% of rated current for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication Options	RS-485, Profibus, Ethernet
Output Power Range	0.4 kW to 630 kW
Cooling Method	Forced air cooling (fan) (Varies by model)
Operating Temperature	-10 to +50°C (Varies by model, may be derated at higher temperatures)
Storage Temperature	-20 to +65°C
Humidity	95% RH or less (non-condensing)
Altitude	Up to 1000 m above sea level (Derating may be required above 1000 m)
Enclosure Rating	IP20
Model	FR-A700, FR-F700, FR-E700, FR-D700, FR-S700
