Table9.77 Explanation of Parameter setting screen (Continued)
Item Description
Network range assignment
The network range is assigned.
This setting is available when "MNET/H mode (Control station)", "MNET/10 mode
(Control station)", or "MNET/H Ext. mode (Control station)" is selected for "Network type".
Total stations
Set the total stations (including the control station) on the target network.
(Initial value: 2, Setting range: 2 to 64)
Assignment method
The device range input method can be switched between Points/Start and Start/End.
(Initial value: "Start/End")
Monitoring time
Set the monitoring time for the link scan time. (Unit: 10ms)
(Initial value: 200, Setting range: 1 to 200)
Switch screens
Select the link device to which network range will be assigned.
"Low speed LB" and "Low speed LW" can be set when "MNET/H mode (Control station)"
or "MNET/H Ext. mode (Control station)" is selected for "Network type".
(Initial value: "LB/LW setting", Setting range: "LB/LW setting", "LX/LY setting (1)", "LX/LY
setting (2)")
Points
Set the No. of the link device points assigned to the target station.
This setting is available when "Points/Start" is selected for "Assignment method".
(Initial value: "(Blank)", Setting range: This section (1)(a))
Start
Set the start No. of the link device assigned to the target station.
(Initial value: "(Blank)", Setting range: This section (1)(a))
End
Set the end No. of the link device assigned to the target station.
This setting is available when "Start/End" is selected for "Assignment method".
(Initial value: "(Blank)", Setting range: This section (1)(a))
button
Sets the selected station as an I/O master station of the link device (LX/LY) or cancels
the setting.
This button can be used when "LX/LY setting (1)" or "LX/LY setting (2)"is selected for
"Switch screens".
button
Sets the selected station as a reserved station, or cancels the setting.
button
Displays the Equal assignment screen.( This section (4))
button
Displays the Supplementary setting screen.( This section (5))
button
Erases the "Points", "Start", and "End" settings and sets the initial values to "Total
stations" and "Monitoring time".
Module information Target settingError history monitor Other station monitor Online operation
Parameter setting
Specify I/O master Sta.
Specify reserved Sta.
Equal assignment
Supplementary setting
Clear
To Next Page
