5-36 Installing the Operating System with Express Setup
Network Driver
[When PROSet is not installed]
1. Click Start menu and click [Network and Dial-Up Connection].
The [Network and Dial-Up Connection] dialog box appears.
2. Right-click [Local Area Connection] and click [Properties] from pop-up menu.
The [Local Area Connection Properties] dialog box appears.
3. Click [Configure].
The property dialog box for network adapter appears.
4. Click the [Advanced] and specify the [Link Speed & Duplex]value the same as the value specified for HUB.
5. Click [OK] on the property dialog box for network adapter.
6. Click [OK] on the [Local Area Connection Properties] dialog box.
Also, add or delete any protocols and services if necessary. You can operate the process from [Network and Dial-up
Connection] to display the property dialog box for local area network.
NOTE: We recommend you to add [Network Monitor] at [AddingServices]. [Network
Monitor] can monitor the frame (or the packet) that the computer installing [Network
Monitor] sends or receives. This tool is valuable when analyzing network trouble. For
information on how to install the tool, see the "Setting for Solving Problems" described
later in this chapter.
[When PROSet is installed]
1. Double-click [Intel(R) PROSet Wired] on the [Control Panel] window.
The [Intel(R) PROSet for Wired Connections] dialog box appears. Double-click the [IntelR PROSet ] icon.
2. Put the cursor to the network driver in the list.
3. Click the [Advanced] and specify the [Link Speed & Duplex] value the same as the value specified for HUB.
Also specify the other network driver with the same progress above.
To Next Page
