Upgrading Your Server 9-21
Adaptec 29320
Black cable Red cable
Ultra160 SCSI Controller
Black cable
Red cable
Red pin Black pin
After the installation, set the transfer rate of the board, those of the devices connected to the board, and other
parameters by using the SCSI BIOS utility of the SCSI controller. Refer to the document coming with the
board for the details of the settings and the procedures.
