Configuring Your Server 4-35
Configuring RAID
Take the following steps to configure RAID.
IMPORTANT:
îš„ Once the array is created and its properties are assigned, you cannot change the array
properties using the ACU.
îš„ The hard disk drives for RAID configuration must be physically formatted. See "Using
the Disk Utilities" described later.
îš„ Be sure to set Bootable according to "Managing Arrays" using the BIOS SETUP utility.
Otherwise, the memory dump cannot be collected at system failure, or other problem
will be raised.
1. Start the ACU.
See "Running the Array Configuration Utility (ACU)" described earlier.
2. Use the cursor key to select [Array Configuration Utility] from the Options menu, and press Enter.
3. From the main menu, select [Create Array] and press Enter.
To Next Page
