For example, to apply ‘Comp 3’ to the main Switcher, press and hold CTRL, then punch the third button on
the DSK row, then release CTRL. The same thing goes for a delegated M/E row, save that you will press the
appropriate button (from 1-16) in the KEY row.
Note: When M/Es are multi-selected, only the lowest index M/E is affected by CS Comp operations.
You can also store or update the 16 Comps for the currently delegated M/E or main Switcher. To do so, press
SHIFT + CTRL along with the DSK/ KEY row button corresponding to the target Comp.
21.3.7 PREVIZ
To transfer the current state of the main Switcher to PREVIZ, press CTRL + the BKGD delegate button
(located in the Transition control group). Note that for multi-selected M/Es, the state of the lowest
numbered M/E only is sent to PREVIZ.
To fetch the current PREVIZ state back to the main Switcher, press SHIFT + CTRL along with the
Switcher BKGD button.
Hint: As mentioned previously, press FOLLOW PVW in the M/E Delegate to delegate the M/E rows to
PREVIZ.
21.3.8 MEDIA PLAYERS
DELEGATE GROUP
FIGURE 21-15
The DELEGATE group contains buttons for TriCaster’s DDR1, DDR2, GFX1, GFX2, and SND (Sound) modules.
This selection determines which Media Player is being controlled at the moment. (Support for multi-selection
allows you to do things like start and stop both DDRs at the identical moment.)
PREV/NEXT PRESET
FIGURE 21-16
