4. Click the + sign that appears when you move the mouse over the label below the effect thumbnail to
open a Media Browser.
5. Click the NewTek label under the LiveSet heading in the Media Browser, and choose “3D Center
L.LiveSet” from the “Night Beat” folder in the file pane at right.
This M/E provides the left angle for the center desk shot of the ultimate 3D result.
6. Choose another free M/E, and set it up exactly as described above – but this time choose “3D Center
R.LiveSet” from the “Night Beat” folder.
This second M/E provides the right angle for the 3D effect.
7. Set a third M/E pane to Effect mode, and assign “3D Anaglyph (Red, Cyan).LiveSet” from the “3D”
folder to it.
8. In this third M/E pane, assign the left angle M/E prepared earlier to Input A, and the M/E you
configured as the right angle to Input B.
9. Select this third M/E on the main Switcher’s Program row, and view the result through red/cyan 3D
glasses. (Note that the anaglyph effect is maintained even through a LiveSet zoom.)
Hint: If you assign suitable left and right images to the Input B rows of the respective left and right M/Es,
the desk front monitor imagery will also be shown in 3D.
A.3.5 SET UP THE ‘METROPOLIS A’ LIVESET?
Note: This number of sources required for this effect limits its use to TriCaster 8000.
Metropolis is a ‘million dollar set’, and provides endless opportunities for creative use. There are actually
two versions of this set, labeled A and B, with multiple shots in each group. The second of these groups (‘B’)
employs tighter camera shots with less video sources visible at one time, and requires no special care to
configure.
Metropolis A, however, is a complex set, with three different primary talent positions as well as numerous
secondary displays. When viewed in its widest zoom angle, it can require as many as 8 different sources to
supply all of these – not counting the Key (overlay) layers.
FIGURE 21-73
