the effect is complete. At that point, it pops back to full brightness, just as the onscreen T-Bar returns to
the top of its stroke.
3. In a mixed delegate situation (BKGD along with one or more KEY layers) the T-Bar is lit it medium blue,
and conforms to the BKGD behavior described above.
4. If one or more KEY layers are delegated without BKGD, the T-Bar color is purple. When the KEY layer (or,
for multi-KEY selections, the first KEY layer) is fully displayed, T-Bar lighting is at its brightest. Removing
the layer dims the illumination.
21.3.14 MAIN TRANSITION
1. Just as you would expect, the illumination of this T-Bar uses red-green coloration, standard color coding
for Program and Preview rows.
2. As for M/Es, described earlier, DSK-only delegate operations result in the T-Bar being lit in purple.
3. Mixed mode (BKGD plus DSK delegates) likewise result in blue illumination, just like the T-Bar behavior
previously described for M/Es.
21.3.15 PTZ CONTROL
Pan, tilt, zoom control over connected robotic cameras is also provided using the joystick.
Note: Joystick operations do not affect stored PTZ preset values.
To delegate the joystick to control a PTZ camera assigned to a specific TriCaster input, hold down SHIFT
button on the control surface and press a button (1-8) in the M/E Delegate group. (Afterward, the button
corresponding to the current PTZ camera selection will light whenever SHIFT is pressed.)
Pan: With SHIFT depressed, tilt the joystick left-right.
Tilt: With SHIFT depressed, tilt the joystick backward-forward.
Zoom: With SHIFT depressed, twist the joystick clockwise or counter-clockwise.
Focus: When Auto is off, and with SHIFT + CTRL both pressed, twist the joystick clockwise or counter-
clockwise.
o Auto Focus toggle: With SHIFT + CTRL held down, press the joystick button.
Preset selection: Press CTRL + LIVESET SHOT (1-8) to choose a preset for the selected camera.
Press CTRL + RATE (M/E Transition group) to adjust the camera’s Animation Speed.
Hold down SHIFT and press the top joystick button to update the current PTZ preset (position, zoom and
thumbnail icon).
