Useful software
- 259 -
Color Correct Utility
This section explains how to adjust the color using the Color Correct Utility.
Set up each printer driver.
To use the Color Correct Utility, you will have to login to the PC as a user with administrator privileges.
Changing palette colors
You can use the Color Correct Utility to specify colors of the palette selected in software like Microsoft Excel.
For Windows
1
Click [Start] and select [Okidata] - [Color Correct Utility].
2
Select [Office Palette Tuning], and click [Next]. and click [Next].
3
Select the device to be adjusted, and click [Next].
4
Select the name of the setting, and click [Print Sample].
If the settings are initialized after the printer driver has been updated and reinstalled, start the Color Correct
Utility to automatically reset the name of the color tuning.
Check that the color tuning name is displayed on the [Select setting] screen.
5
Click [Next].
6
Click [Print Test].
7
Compare the color palette on the screen with the colors of the printed color sample for
adjustment.
The color marked with an x cannot be adjusted.
8
Click the color you want to adjust.
9
Check the adjustable range of X and Y from the drop-down list.
The adjustable value varies with the specific color.
10
Check the printed color samples, select the most suitable color within the adjustable range, and
then check the X and Y values.
11
Select the values you checked in Step 10, and click [OK].
To Next Page
