Management of this machine
- 212 -
11
Click [Submit].
The new settings will take effect after the network function of the machine has been reset.
12
When the machine is online, power off the machine.
13
Remove the LAN cable from the machine.
14
Go to "Connecting this machine to the authentication switch".
Connecting this machine to the authentication switch
1
Check that this machine is powered off.
2
Connect the LAN cable to the network interface connector of this machine.
3
Connect the other end of the LAN cable to the authentication port of the authentication switch.
4
Power on this machine.
5
Set the IP address of this machine.
Setting IEEE802.1X (Wireless LAN)
You can set IEEE802.1X authentication with a wireless LAN. First, access the web page of this machine via a
wired LAN to set IEEE802.1X authentication, and then set the wireless connection on the web page.
Setting with EAP-TLS
1
Open the web page of this machine.
Opening the web page(P.200)
2
Log in as an administrator.
3
Select [Admin Setup].
Logging in as an administrator(P.200)
4
Select [Network] - [IEEE802.1X].
5
Select [Disable] in [IEEE802.1X].
6
Select [EAP-TLS] in [EAP Type].
7
Input the user name in [EAP User].
8
Check [Not use SSL/TLS Certificate for EAP authentication], and click [Import].
If you select [Use SSL/TLS Certificate for EAP authentication], the certificate must be preset from the [SSL/TLS]
menu.
9
Select the certificate file.
Only PKCS#12 files can be imported.
10
Input the certificate password, and click [OK].
11
Select [Authenticate Server], and click [Import].
When you select [Not Authenticate Server], go to Step 13.
To Next Page
