Oki C650 - How to Use Levers L1 and L2

Basic operations
- 88 -
How to use levers L1 and L2
When the front cover is open, you will find the L1 lever and the L2 lever. This section describe how to use
these levers.
Lever L1
Used to replace the image drum and to clean the LED head.
Replacing the image drum(P.303)
Cleaning the LED head(P.312)
After opening the front cover, operate the L1 lever first and then the L2 lever.
After the operation, only the output tray is raised.
No. Name
1
Output tray
2
Image drum basket
When closing, close the output tray first. Then, press the L1 lever, and close the front cover with your both
hands firmly.
