Omron 3G3RX - Page 415

App-20
Appendix-1 Parameter List
Appendix
Torque limit
b042
Torque limit 2
(Four-quadrant mode
reverse regeneration)
[TRQ limit RV/REG]
0 to 200 (0.4 to 55 kW)
0 to 180 (75 to 132 kW)
no (Torque limit disabled)
150 No %
4-57
4-59
b043
Torque limit 3
(Four-quadrant mode
reverse power
running)
[TRQ limit RV/POW]
0 to 200 (0.4 to 55 kW)
0 to 180 (75 to 132 kW)
no (Torque limit disabled)
150 No %
b044
Torque limit 4
(Four-quadrant mode
forward regeneration)
[TRQ limit FW/REG]
0 to 200 (0.4 to 55 kW)
0 to 180 (75 to 132 kW)
no (Torque limit disabled)
150 No %
b045
Torque LADSTOP
selection
[TRQ limit LADSTOP]
00: OFF (Disabled)
01: ON (Enabled)
00 No  4-59
Others
b046
Reverse rotation
prevention selection
[Rev RUN protect]
00: OFF (Disabled)
01: ON (Enabled)
00 No  4-59
b049
Dual rate selection
[Dual rate select]
00: CT (Constant torque)
01: VT (Variable torque)
00 No 
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
