App-33
Appendix-1 Parameter List
Appendix
Others
C101
UP/DWN selection
[UP/DWN memory
mode]
00: Not save (Do not store the frequency
data)
01: Save (Store the frequency data)
00 No  4-90
C102
Reset selection
[Reset mode select]
00: ON-RESET (Trip reset at power-on)
01: OFF-RESET (Trip reset when the power
is OFF)
02: On in Trip (Enabled only during trip (Reset
when the power is ON))
03: Trip RESET (Trip reset only)
00 Yes 
4-87
4-137
C103
Reset frequency
matching selection
[Restart after reset]
00: 0 Hz start
01: f-match (Frequency matching start)
02: Actv.f-match (Active Frequency Matching
restart)
00 No  4-87
Meter adjustment
C105
FM gain setting
[FM gain adjust]
50 to 200 100 Yes % 4-110
C106
AM gain setting
[AM gain adjust]
50 to 200 100 Yes %
4-111
C107
AMI gain setting
[AMI gain adjust]
50 to 200 100 Yes %
C109
AM bias setting
[AM bias adjust]
0 to 100 0 Yes %
C110
AMI bias setting
[AMI bias adjust]
0 to 100 20 Yes %
Terminal
C111
Overload warning
level 2
[Overload warn lvl 2]
0.0 to 2.00 × Rated current (0.4 to 55 kW)
0.0 to 1.80 × Rated current (75 to 132 kW)
Rated
current
No A 4-49
Adjustment
C121
O zero adjustment
[[O] 0 calibration]
0 to 65535
Factory
default
Yes 
C122
OI zero adjustment
[[OI] 0 calibration]
0 to 65535
Factory
default
Yes 
C123
O2 zero adjustment
[[O2] 0 calibration]
0 to 65535
Factory
default
Yes 
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
