It is possible to specify the data type for addresses allocated for symbols.
The data types that can be specified inside function blocks may be different from the types that be spec-
ified outside function blocks. The data types that can be used for each are specified in the following
table.
*1 Data types will be converted as follows in ST programming.
• UINT BCD: WORD
• UDINT BCD: DWORD
• ULINT BCD: LWORD
• CHANNEL: WORD
*2 These data types cannot be used in ST programming. A program error will occur.
*3 Only internal symbols in function blocks written with ladder diagrams.
5-5-7 Symbol Data Types
Data Types That Can Be Set for Symbols
Data type Symbols in programming Variable in function blocks
BOOL (bit) OK OK
UINT (one-word unsigned binary) OK OK
UDINT (two-word unsigned binary) OK OK
ULINT (four-word unsigned binary) OK OK
INT (one-word signed binary) OK OK
DINT (two-word signed binary) OK OK
LINT (four-word signed binary) OK OK
UINT BCD (one-word unsigned binary)
*1
OK No
UDINT BCD (two-word signed binary)
*1
OK No
ULINT BCD (four-word signed binary)
*1
OK No
REAL (two-word floating point) OK OK
LREAL (four-word floating point) OK OK
CHANNEL (word)
*1
OK No
NUMBER (constant or number)
*2
OK No
WORD (one-word hexadecimal) OK OK
WORD (two-word hexadecimal) OK OK
LWORD (four-word hexadecimal) OK OK
STRING (character string: 1 to 255 ASCII characters) OK OK
TIMER No OK
COUNTER No OK
User-defined data types (data structures) OK
OK
*3
