CJ2 CPU Unit Software User’s Manual
Introduction
Thank you for purchasing a CJ-series CJ2H-CPU6@(-EIP) or CJ2M-CPU@@ Programmable Controller.
This manual contains information required to use the CJ2H-CPU6@(-EIP) or CJ2M-CPU@@. Please
thoroughly read and understand this manual before you use the CJ2H-CPU6@(-EIP) or CJ2M-CPU@@.
This manual is intended for the following personnel, who must also have knowledge of electrical sys-
tems (an electrical engineer or the equivalent).
• Personnel in charge of installing FA systems
• Personnel in charge of designing FA systems.
• Personnel in charge of managing FA systems and facilities.
CJ-series CJ2 CPU Units
• CJ2H-CPU6@-EIP
• CJ2H-CPU6@
•CJ2M-CPU3@
•CJ2M-CPU1@
In this manual, the following notation is used to indicate the CPU Units.
• CJ2H-CPU6@(-EIP): Indicates the CJ2H-CPU6@-EIP and CJ2H-CPU6@ CPU Units.
• CJ2M-CPU@@: Indicates the CJ2M-CPU3@ and CJ2M-CPU1@ CPU Units.
Optional Pulse I/O Modules can be used for pulse I/O with a CJ2M CPU Unit.
Intended Audience
Applicable Products
CJ2 Series
CJ1H-CPU@@H-R
CJ1H-CPU@@H
CJ1G-CPU@@H
CJ1G -CPU@@P
(Loop CPU Units)
CJ1-H CPU Units
CJ1 CPU Units
CJ1G-CPU@@
CJ1M CPU Units
CJ1M-CPU@@
CJ-series Power Supply Units
CJ-series Basic I/O Units
CJ-series CPU Bus Units
CJ-series Special I/O Units
CS1H-CPU@@H
CS1G-CPU@@H
CS1-H CPU Units
CS-series Power Supply Units
CS-series Basic I/O Units
CS-series CPU Bus Units
CS-series Special I/O Units
CS Series
CS1 CPU Units
CS1H-CPU@@(-V)
CS1G-CPU@@(-V)
CS1D CPU Units
CS1D CPU Units
for Duplex Systems
CS1D-CPU@@H
CS1D-CPU@@S
CS1D-CPU@@P
NSJ5-TQ@@(B)-G5D
NSJ5-SQ@@(B)-G5D
NSJ8-TV@@(B)-G5D
NSJ10-TV@@(B)-G5D
NSJ12-TS@@(B)-G5D
NSJ Controllers
NSJ-series Expansion Units
NSJ Series
NSJ5-TQ@@(B)-M3D
NSJ5-SQ@@(B)-M3D
NSJ8-TV@@(B)-M3D
NSJ Controllers
CJ2H-CPU6@-EIP
CJ2H-CPU6@
CS1D CPU Units
for Simplex Systems
CS1D Process-control CPU Units
Note: A special Power Supply Unit must
be used for CS1D CPU Units.
CJ2 CPU Units
CJ2H CPU Units
CJ2M CPU Units
CJ2M-CPU3@
CJ2M-CPU1@
Pulse I/O Module for
CJ2M CPU Units
To Next Page
