8 I/O Allocations and Unit Settings
8-2
CJ2 CPU Unit Software User’s Manual
8-1 I/O Allocations
Allocating words in I/O memory in the CPU Unit for exchanging data between the CPU Unit and other
Units is called I/O allocation. Memory is allocated differently to Basic I/O Units, Special I/O Units, and
CPU Bus Units.
8-1-1 I/O Allocations
Special I/O Unit Area
The words that are allocated
are determined by the unit number.
25 words allocated per Unit
CPU Bus Unit Area
10 words allocated per Unit
Special I/O Units
2
ON
4
TERM
RD2
SD2
RDY
NO.
UNIT
ERH
OFF
WIRE
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
ERC
RUN
SCU41
RD1
TER1
SD1
PORT1
(RS422
/485)
PORT2
CIO 0000
CIO 1000
CIO 0159
CIO 1500
CIO 1899
CIO 2000
CIO 2959
Memory is allocated in units of 16 bits
OD211
0123
4567
89 1
0 11 12 1
3 14
15
*1
Basic I/O Units
*1 The first word on each Rack can be set from the CX-Programmer to an address
between CIO 0000 and CIO 0999 (default setting: consecutive allocation from
CIO 0000).
Allocations
The words that are allocated
are determined by the position
of the Unit.
CPU Bus Units
I/O Memory Areas in CPU Unit
I/O Area
The words that are allocated
are determined by the unit number.
Special
Units
