Omron CJ2 CPU UNIT SOFTWARE User Manual

A-105
Appendices
CJ2 CPU Unit Software User’s Manual
A-2 Instruction Execution Times and Number of Steps
App
A-2-30 Other Instructions
FAILURE POINT
DETECTION
FPD 269 4 111 188 Bit address output,
time monitored
107 202 Bit address output,
first error detection
129 242 Message characters
output, time moni-
tored
159 244 Message characters
output, first error
detection
A-2-30 Other Instructions
Instruction Mnemonic FUN No. Length (steps)
ON execution time (µs)
Conditions
CJ2H
CPU6@(-EIP)
CJ2M-
CPU@@
SET CARRY STC 040 1 0.048 0.060 ---
CLEAR CARRY CLC 041 1 0.048 0.060 ---
SELECT EM BANK EMBC 281 2 7.6 14.6 ---
EXTEND MAXIMUM
CYCLE TIME
WDT 094 2 7.6 17.1 ---
SAVE CONDITION
FLAGS
CCS 282 1 5.8 8.3 ---
LOAD CONDITION
FLAGS
CCL 283 1 6.4 9.9 ---
CONVERT ADDRESS
FROM CV
FRMCV 284 3 9.4 15.7 ---
CONVERT ADDRESS
TO CV
TOCV 285 3 to 4 10.3 18.2 ---
DISABLE PERIPH-
ERAL SERVICING
IOSP 287 1 --- --- ---
ENABLE PERIPH-
ERAL SERVICING
IORS 288 1 --- --- ---
A-2-31 Block Programming Instructions
Instruction Mnemonic FUN No.
Length
(steps)
ON execution time (µs)
Conditions
CJ2H
CPU6@(-EIP)
CJ2M-
CPU@@
BLOCK PROGRAM
BEGIN
BPRG 096 2 7.8 14.1 ---
BLOCK PROGRAM
END
BEND 801 1 8.8 13.4 ---
BLOCK PROGRAM
PAU SE
BPPS 811 2 5.4 8.4 ---
BLOCK PROGRAM
RESTART
BPRS 812 2 3.6 4.8 ---
Instruction Mnemonic FUN No.
Length
(steps)
ON execution time (µs)
Conditions
CJ2H
CPU6@(-EIP)
CJ2M-
CPU@@
