Appendices
A-106
CJ2 CPU Unit Software User’s Manual
CONDITIONAL
BLOCK EXIT
(Execution
condition)
EXIT
806 1 8.6 13.2 Block exited (input
condition ON)
2.0 2.6 Block not exited
(input condition OFF)
CONDITIONAL
BLOCK EXIT
EXIT (bit
address)
806 2 9.8 14.8 Block exited (bit ON)
3.6 4.2 Block not exited (bit
OFF)
CONDITIONAL
BLOCK EXIT (NOT)
EXIT NOT
(bit address)
806 2 3.6 4.3 Block exited (bit
OFF)
8.9 14.9 Block not exited (bit
ON)
Branching IF (execution
condition)
802 1 1.9 2.4 IF true (input condi-
tion ON)
3.8 6.4 IF false (input condi-
tion OFF)
IF (bit
address)
802 2 3.2 4.0 IF true (bit ON)
5.1 8.0 IF false (bit OFF)
Branching (NOT) IF NOT (bit
address)
802 2 5.1 8.2 IF true (bit OFF)
3.2 4.1 IF false (bit ON)
Branching ELSE 803 1 3.5 5.7 IF true
5.3 7.3 IF false
Branching IEND 804 1 5.3 8.5 IF true
2.0 2.4 IF false
ONE CYCLE AND
WAIT
WAIT (execu-
tion condi-
tion)
805 1 10.0 15.9 Do not wait (input
condition ON)
1.4 1.9 Wait (input condition
OFF)
WAIT (bit
address)
805 2 9.2 13.5 Do not wait (bit ON)
2.6 3.7 Wait (bit OFF)
ONE CYCLE AND
WAIT (NOT)
WAIT NOT
(bit address)
805 2 9.2 13.5 Do not wait (bit OFF)
2.8 3.7 Wait (bit ON)
HUNDRED-MS TIMER
WAIT
TIMW 813 3 15.6 22.9 Default setting
16.0 23.2 Normal execution
TIMWX 816 3 15.1 21.7 Default setting
16.0 23.2 Normal execution
TEN-MS TIMER WAIT TMHW 815 3 15.7 22.6 Default setting
17.5 24.9 Normal execution
TMHWX 817 3 15.2 22.1 Default setting
16.4 23.4 Normal execution
COUNTER WAIT CNTW 814 4 13.7 20.5 Default setting
13.4 19.8 Normal execution
CNTWX 818 4 13.1 19.5 Default setting
13.5 19.7 Normal execution
Loop Control LOOP 809 1 4.6 9.1 ---
Instruction Mnemonic FUN No.
Length
(steps)
ON execution time (µs)
Conditions
CJ2H
CPU6@(-EIP)
CJ2M-
CPU@@
To Next Page
