10 CPU Unit Functions
10-74
CJ2 CPU Unit Software User’s Manual
5 Select the Transfer (PC to PLC) Button to transfer the settings to the CPU Unit.
6 Turn ON the Trace Start Bit (A508.15) or press the following button.
The following display will appear when the trigger condition has been satisfied.
Click this button to start
tracing data.
Indicates when the trigger
condition is met.
