Omron CJ2 CPU UNIT SOFTWARE User Manual

A-11
Appendices
CJ2 CPU Unit Software User’s Manual
A-1 Instruction Functions
App
A-1-4 Timer and Counter Instructions
TENTH-MS
TIMER
TIMU
(BCD)
541 TIMU(541)/TIMUX(556) operates a decrementing timer with
units of 0.1-ms. The setting range for the set value (SV) is 0 to
0.9999 s for BCD and 0 to 6.5535 s for binary (decimal or
hexadecimal).
Output Required
TIMUX
(BIN)
556
HUNDREDTH-
MS TIMER
TMUH
(BCD)
544 TMUH(544)/TMUHX(557) operates a decrementing timer with
units of 0.01-ms. The setting range for the set value (SV) is 0
to 0.09999 s for BCD and 0 to 0.65535 s for binary (decimal or
hexadecimal).
Output Required
TIMUX
(BIN)
556
ACCUMULA-
TIVE TIMER
TTIM
(BCD)
087 Output Required
TTIMX
(Binary)
555
Instruction Mnemonic Code Symbol/Operand Function Location
Execution
condition
TIMU (541)
N
S
N: Timer number
S: Set value
Timer input
Timer PV
Completion
Flag
Completion
Flag
Timer input
ON
OFF
ON
OFF
0
SV
ON
OFF
ON
OFF
0
SV
Timer PV
Timer Input Turned OFF before Completion
Flag Turns ON
TIMUX(556)
N
S
N: Timer number
S: Set value
TMUH(544)
N
S
N: Timer number
S: Set value
Timer input
Timer PV
Completion
Flag
Completion
Flag
Timer input
ON
OFF
ON
OFF
0
SV
ON
OFF
ON
OFF
0
SV
Timer PV
Timer Input Turned OFF before Completion
Flag Turns ON
TMUHX(557)
N
S
N: Timer number
S: Set value
TTIM(087)
N
S
N: Timer number
S: Set value
Reset
input
Timer
input
Timer input
Timer PV
SV
Reset input
PV
maintained.
Timing
resumes.
TTIM(087)/TTIMX(555) operates an incrementing timer
with units of 0.1-s. The setting range for the set value
(SV) is 0 to 999.9 s for BCD and 0 to 6,553.5 s for
binary (decimal or hexadecimal).
Completion
Flag
TTIMX(555)
N
S
N: Timer number
S: Set value
Reset
input
Timer
input
