Appendices
A-90
CJ2 CPU Unit Software User’s Manual
DOUBLE SIGNED
BCD TO BINARY
BISL 472 4 to 5 3.7 4.1 Data format
setting No. 0
3.6 4.1 Data format
setting No. 1
3.7 4.2 Data format
setting No. 2
3.7 4.2 Data format
setting No. 3
SIGNED BINARY TO
BCD
BCDS 471 4 3.7 4.0 Data format
setting No. 0
3.7 4.1 Data format
setting No. 1
3.7 4.2 Data format
setting No. 2
3.7 4.2 Data format
setting No. 3
DOUBLE SIGNED
BINARY TO BCD
BDSL 473 4 to 5 4.0 4.5 Data format
setting No. 0
4.0 4.6 Data format
setting No. 1
4.0 4.6 Data format
setting No. 2
4.1 4.6 Data format
setting No. 3
GRAY CODE CON-
VERSION
GRY 474 4 26.5 49.1 8-bit binary
27.6 51.1 8-bit BCD
30.9 57.2 8-bit angle
35.3 66.0 15-bit binary
36.3 68.0 15-bit BCD
39.6 74.0 15-bit angle
GRAY CODE TO
BINARY CONVERT
GRAY_BIN 478 3 0.1 0.3 ---
DOUBLE GRAY
CODE TO BINARY
CONVERT
GRAY_BINL 479 3 to 4 0.1 0.4 ---
BINARY TO GRAY
CODE CONVERT
BIN_GRAY 480 3 0.1 0.3 ---
DOUBLE BINARY TO
GRAY CODE CON-
VERT
BIN_GRAYL 481 3 to 4 0.1 0.4 ---
FOUR-DIGIT NUM-
BER TO ASCII
STR4 601 3 8.4 14.2 ---
EIGHT-DIGIT NUM-
BER TO ASCII
STR8 602 3 to 4 10.2 16.4 ---
SIXTEEN-DIGIT NUM-
BER TO ASCII
STR16 603 3 15.8 28.2 ---
ASCII TO FOUR-
DIGIT NUMBER
NUM4 604 3 to 4 10.5 18.5 ---
ASCII TO EIGHT-
DIGIT NUMBER
NUM8 605 3 14.8 27.1 ---
Instruction Mnemonic FUN No. Length (steps)
ON execution time (µs)
Conditions
CJ2H
CPU6@(-EIP)
CJ2M-
CPU@@
