Omron CJ2 CPU UNIT SOFTWARE User Manual

Appendices
A-174
CJ2 CPU Unit Software User’s Manual
Performance
specifications
CPU Bus Unit
refreshing (tag
data links with
EtherNet/IP
Unit)
100 µs + (No. of
words transferred ×
0.33 µs)
100 µs + (No. of
words transferred ×
0.7 µs)
200 µs + (No. of words transferred
× 0.7 µs)
270 µs + (No. of
words transferred
× 0.7 µs)
200 µs + (No. of
words transferred
× 0.7 µs)
Maximum EM
Area capacity
32K words × 25
banks
32K words × 4 banks 32K words × 13 banks
Source/com-
ment memory
3.5 MB 1,024K bytes 2 MB
Function block
definitions,
actions, and
transitions
2,048 CJ2M-
CPU@1/CPU@2/
CPU@3: 256
CJ2M-
CPU@4/CPU@5:
2,048
1,024
Applicable
Memory Cards
30, 64, 128, 256, or
512 MB
128 Mbytes
256 Mbytes
512 Mbytes
30, 64, or 128 MB
Number of
cyclic tasks
128 tasks 32 tasks
Communica-
tions ports
(internal logic
ports)
8 + 64 ports 8 ports
Increase in
cycle time for
online editing
Approx. 1 ms Approx. 8 ms Approx. 14 ms Approx. 8 ms.
Maximum num-
ber of Expan-
sion Racks
3 Racks 7 Racks
Maximum num-
ber of Interrupt
Input Units
2 Units 4 Units
Maximum num-
ber of CPU Bus
Units
15 Units CJ2M-CPU1@: 16
Units
CJ2M-CPU3@: 15
Units
16 Units
Inner Boards Not applicable. Applicable
Item
CJ Series CS Series
CJ2 CPU
Units
CJ2M CPU Units
CJ1-H-R
CPU Units
CJ1-H
CPU Units
CJ1-M
CPU Units
CS1-H
CPU Units
