Section 5 Object Operations 5-7 Address Settings
NS-Designer Operation Manual NS-Designer Operation Manual NS-Designer Operation Manual
Importing and Exporting CSV Files
Use the CSV file import and export functions to edit settings efficiently.
1. Click the Export CSV or Import CSV Button.
2. To export files, specify the save directory and the file name and then click the Save Button. If im-
porting from a CSV file, select the name of the file to be imported and click the Open Button.
3. An error check is performed when files are imported and any detected errors are displayed in a
dialog box, like the one shown below.
1
2
No. Details
1 Displays the line number in the CSV file data where the error was found.
Displays the error number. Refer to the following table for details. 2
Error No. Details Countermeasure
1 Format error in imported CSV file. Check that the imported file is in CSV format.
Check that the settings are valid.
2 Insufficient memory. Settings
contained in CSV file cannot be
imported.
Close any unnecessary applications and
re-execute the import operation.
3 Could not open the CSV file. CSV
file could not be imported.
Check that the file is not being used by another
application. If the file is being used by another
application, close the file and then re-execute
the import operation.
The output CSV file will be displayed in the following format.
(When displayed using Microsoft Excel.)
The host ID is the number automatically allocated to the host when it is registered. The host ID does
not change even if it is different from the number in the Register Host Dialog Box or if the host is de-
leted.
5-40
