22
NV-Designer Window Names and Menus Section 3-2
Pop-up Menus on Base Screens
Draw Select Used to select a character string, graphic, functional part,
etc.
Text Creates a character string.
Line Creates a straight line.
Continuous line Creates continuous lines.
Rectangle Creates a rectangle.
Pie/Oval Creates a circle or oval.
Arc Creates a circular or oval arc.
Spline Creates a curved line.
Sector Creates a circular or oval sector.
Rounded Rectangle Creates a square with rounded corners.
Polygon Creates a polygon.
Fill In Fills areas enclosed by lines and graphics with a color.
Character Type Sets the language, font, character size, attributes (e.g.,
bold), and colors (character and background colors).
Color Setup Sets the colors and patterns for graphics.
Line Type Sets the line thickness and type.
Toolbar Resource Report Displays the resource report (amount of free memory and
memory used by NV configuration, base screens, and key-
board screens).
Base Screen Memory
Usage
Displays the amount of memory used by the base screens.
Displays the amount of memory and the communications
addresses used by the parts.
NV-Designer Configu-
ration
Displays the NV-Designer Configuration Dialog Box.
Sets the configuration of the NV-Designer screen display,
the folder where the parts libraries used by the NV-Designer
are stored, the current folder, whether to enable automatic
backup, the backup time interval, items for creating graphics,
menu and dialog languages, and whether to enable switch-
ing the display language.
Convert PLC Model Convert Changes the model of the selected PLC in the file that is
being edited.
NV Model Convert Changes the model of PT in the file that is being edited.
Close All Closes all open base screens.
Window Cascade Overlaps more than one base screen and displays them.
Arrange Displays more than one base screen side-by-side.
Arrange Icons Returns the toolbar icons to the defaults.
Help Contents Displays the contents of NV-Designer help.
Keyword Displays the window for keyword-based searches of NV-
Designer help.
About NV-Designer Displays the version of the NV-Designer.
Pop-up Menus Description
Paste Pastes the parts.
Screen Attribute Sets the background colors and patterns.
Menu Submenu/Command Description
