Starting the NV-Designer and Creating New Projects Section 5-1
Area).
Example: With a CP-series PLC, CIO 0 to CIO 2 are allocated to built-in
inputs, so the words allocated to the Bit Area must always be changed from
the defaults.
8. When the NV-Designer is started, a project is created at the same time.
The following Main Window will be displayed.
9. Double-click “0” in the Screen Manager. Base screen 0 and the Parts Li-
brary will open as shown in the following graphic.
Screen manager
Base screen 0
Parts Library
To Next Page
