4-2 Wiring
System Design
4
Connector-Terminal Blocks and Cables
These are used to convert the Servo Drive's control I/O Connector (CN1) signals to a terminal block.
Connector Terminal Block Cable Comments
XW2B-20G4
XW2B-20G5
XW2D-20G6
XW2Z-J-B33
The digits in the model number
indicate the cable length (1 m and
2 m).
Example model number for a 2-m
cable: XW2Z-200J-B33
