Omron OMNUC G Series User Manual

4-25
4-2 Wiring
System Design
4
 Terminal Block Wire Sizes
100-VAC Input: R88D-GNL-ML2
200-VAC Input: R88D-GNH-ML2
Model (R88D-)
GNA5L-
ML2
GN01L-
ML2
GN02L-
ML2
GN04L-
ML2
Item Unit
Power supply capacity kVA 0.4 0.4 0.5 0.9
Main circuit power
supply input
(L1 and L3 or
L1, L2, and L3)
*1
Rated current A 1.4 2.2 3.7 6.6
Wire size --- AWG18 AWG16
Control circuit
power supply input
(L1C and L2C)
Rated current A 0.09 0.09 0.09 0.09
Wire size --- AWG18
Servomotor
connection
terminals
(U, V, W, and GR)
*2
Rated current A 1.2 1.7 2.5 4.6
Wire size --- AWG18
Frame ground
(GR)
Wire size --- AWG14
Screw size --- M4
Torque Nm1.2
Model (R88D-)
GN01H-
ML2
GN02H-
ML2
GN04H-
ML2
GN08H-
ML2
GN10H-
ML2
Item Unit
Power supply capacity kVA 0.5 0.5 0.9 1.3 1.8
Main circuit power
supply input
(L1 and L3, or
L1, L2, and L3)
*1
Rated current A 1.3 2.0 3.7 5.0/3.3
*1
7.5/4.1
*1
Wire size --- AWG18 AWG16
Screw size --- --- --- --- --- ---
Torque Nm --- --- --- --- ---
Control circuit
power supply input
(L1C and L2C)
Rated current A 0.05 0.05 0.05 0.05 0.07
Wire size --- AWG18
Screw size --- --- --- --- --- ---
Torque Nm --- --- --- --- ---
Servomotor
connection
terminals
(U, V, W, and GR)
*2
Rated current A 1.2 1.6 2.6 4.0 5.8
Wire size --- AWG18 AWG16
Screw size --- --- --- --- --- ---
Torque Nm --- --- --- --- ---
Frame ground
(GR)
Wire size --- AWG14
Screw size --- M4
Torque Nm1.2
