Omron OMNUC G Series User Manual

5-96
5-27 Details on Important Parameters
Operating Functions
5
Sets the operational conditions during deceleration and after stopping after the main power supply is
turned OFF with the Undervoltage Alarm Selection (Pn065) set to 0.
The deviation counter will be reset when the power OFF is detected.
Sets the deceleration process and stop status after an alarm is issued by the protective function. The
deviation counter will be reset when an alarm is issued.
Sets the operational conditions to apply during deceleration and after stopping when the Servo is
turned OFF.
Pn No. Parameter name
Setting
range
Unit
Default
setting
Attribute
Pn067 Stop Selection with Main Power OFF 0 to 7 --- 0 B
Setting Explanation
0 and 4 Use dynamic brake to decelerate and remain stopped with dynamic brake.
1 and 5 Use free-run to decelerate and remain stopped with dynamic brake.
2 and 6 Use dynamic brake to decelerate, but free the motor when stopped.
3 and 7 Use free-run to decelerate, and free the motor when stopped.
Pn No. Parameter name
Setting
range
Unit
Default
setting
Attribute
Pn068 Stop Selection for Alarm Generation 0 to 3 --- 0 B
Setting Explanation
0 Use dynamic brake to decelerate and remain stopped with dynamic brake.
1 Use free-run to decelerate and remain stopped with dynamic brake.
2 Use dynamic brake to decelerate, but free the motor when stopped.
3 Use free-run to decelerate, and free the motor when stopped.
Pn No. Parameter name
Setting
range
Unit
Default
setting
Attribute
Pn069 Stop Selection with Servo OFF 0 to 7 --- 0 B
Setting Explanation
0 and 4 Use dynamic brake to decelerate and remain stopped with dynamic brake.
1 and 5 Use free-run to decelerate and remain stopped with dynamic brake.
2 and 6 Use dynamic brake to decelerate, but free the motor when stopped.
3 and 7 Use free-run to decelerate, and free the motor when stopped.
