5-97
5-27 Details on Important Parameters
Operating Functions
5
Sets the regeneration resistor operation and the regeneration overload (alarm code 18) operation.
Set this parameter to 0 if using the built-in regeneration resistor.
If using an external regeneration resistor, be sure to turn OFF the main power when the built-in
thermal switch is activated.
Pn No. Parameter name
Setting
range
Unit
Default
setting
Attribute
Pn06C Regeneration Resistor Selection 0 to 3 --- 0 C
Setting Explanation
0
Sets the regeneration overload to match the built-in regeneration resistor. (regeneration
load ratio below 1%)
1
The regeneration overload (alarm code 18) occurs when the load ratio of the external
regeneration resistor exceeds 10%.
2
The regeneration processing circuit by the external regeneration resistor is activated, but
the regeneration overload does not occur.
3
The regeneration processing circuit is not activated. All regenerative energy is absorbed
by the built-in capacitor.
